Rotary Letterpress Printing Machine
NICKEL EUROPE
FK300 intermittent large cylinder rotary presses
Printing speed: 200RPM
Printing color: 2-10 colors
Max area of rotary printing: 42.4x28cm
Max area of intermittent printing: 36x28cm
Min area of intermittent printing: 5x3cm
Width range of web: 5-30cm
Power of single UV dryer: 5kw/unit
Power supply: 3 phase 380v
Total power: 15kg (not including UV power)
Main size: 10500mmx1600mmx1850mm (LxWxH)
Weight: about 7.7t
Warranty: 12 months starting from the date of signing Acceptance Report for installation and Commissioning.
1. Automatic web guider, unwinding with tension control. No move away when speed up & down. Precise registering.
2. Machine enlarge diameter of the plate cylinder to φ133.50mm, one jump distance of intermittent printing reaches 340mm.
3. HMI touch screen control. Ink control system
4. All our gears and bearings are from Original Japan gears and bearings, stable and high accuracy.
5. Ink rollers are Original German imported rollers.
NICKEL MACHINERY
FD300 shaftless servo-control intermittent letterpresses
Model FD300-6C is a high performance intermittent rotary letterpress, which is researched, developed and manufactured independently by Guangzhou Nickel Printing Machinery Co.,LTD.
It is composed of unwind/rewind unit, letterpress printing units,UV drying units, web guide system, laminating unit and rotary die cut unit,etc.
Printing speed: 200 RPM
Printing color: 2-10 colors
Max printing length: 270mm
Max web width: 300mm
Max printing width: 280mm
Max unwind diameter: 700mm
Max rewind diameter: 700mm
Power supplyl: 3 phase 380V
Total power: 15kw (Ex. UV)
Main size: 8500mmx1600mmx1400mm (LxWxH)
Weight: About 5.5 t
1. LATTICE control system and accurate electric tracking system, simple operation, high efficiency, energy saving and low noise. Die-cutting precision can reaches 0.05mm
2. Web guiding
3. Pre-register system
4. Independent servo motor controled. Registration can be operated by control panel independently.
5. Ink distributing system
6. All our gears and bearings are from Original Japan gears and bearings, stable and high accuracy.
7. Ink rollers are Original German imported rollers.
NICKEL MACHINERY
Nickel Machinery Europe, is the partner in the marketing, sales and after-sales service for Europe of Guangzhou Nickel Printing Machinery Co., Ltd.
